Inner Core - 1.2lb Polypro
Stringer - 2 x EXT Stringer
Rails - 55/45 Double Rails
Channels - Slotted Channels
Slick - HDPE
Deck - WaveCushion 8lb PE Deck Skin
Tail - Clipped Crescent
Additional Features - CNC Shaped, Nose Bulbs, Griptech.
Manufacturing Country - Indonesia
Understanding this bodyboard's technology
 |
1.2lb PP (Indonesia)
1.2lb Polypropylene is a lighter density than the standard 1.9lb Polypropylene. This lighter density offers higher levels of flex and recoil and thereby control. Perfect for cold climates or for the control freak.
|
 |
55/45 Rails
This rail setup leaves less of your rail in the water and offers the rider less contact with the water and therefore better drive and speed throughout all conditions.
|
 |
MiniQuad Concave
The X4 MiniQuad takes the key design factors of our groundbreaking full-length QuadConcave and shrinks it down, focusing on the back half of the board. Starting below the wide-point, the X4 essentially splits the hull in two, combining the glide and flow of a flat bottom with the drive and directional control of the QuadConcave. The X4 MiniQuad is designed to excel in small to medium size surf and for quicker transitions closer to the pocket of the wave.
|
 |
Slotted Channels
Slotted channels are a slender and deeper channel design with less graduation. These channels offer optimum control in bigger and heavier waves.
|
 |
HDPE Slick
HDPE is a high density plastic. This plastic is hard wearing and very stiff. Whilst it will perform as per the norm, it is more prone to creasing when under heavy stress as for its high density properties.
|
 |
Wavecushion 8lb NXLPE (Indo) Decking
Wavecushion decking is a 8lb decking foam. Much like the PE core, the PE decking is soft and flexible. Unlike the PE core, PE decking is used on all top end boards as for the flex and softness which allows riders to create a foam memory. Despite being soft and flexible PE is still extraordinarily durable.
|
 |
Clipped Crescent Tail
The clipped crescent tail is the most popular crescent tail option. This tail will perform when driving, turning, carving and releasing. Clipping the tail allows the rider to maximise their drive and maintain control through the outer concaves and clipped areas.
|
 |
Nose Bulbs
Nose bulbs are a slightly raised area of foam on the nose of the board which create a comfortable spot to grip the nose.
|
| GripTech |
GripTech
Thermoformed textured grips promote superior wax build up for enhanced hand traction.
|
 |
CNC Shaping
Short for “computer numerical control”, CNC machines allow shapers to cut boards perfectly to the mm. CNC machines offer the sharpest possible finish to bodyboard manufacturing.
|
 |
Manufacturing Country: Indonesia/ Broady
The Broady bodyboard factory started in New Zealand in the 80’s but relocated to Indonesia in the early 2000’s. With two of the industries leading shapers at the helm, the Broady Factory uses CNC shaping, buzztech heat lamination and purpose built Aku Shaping in order to produce high performance bodyboards for most of the world’s leading brands.
|
