Bodyboard Core - 1.9lb Polypro
Stringer - 2 x CFT Stringer
Rails - 55/45 Double Rails
Channels - Graduated Channels
Slick - Surlyn
Deck - Wavecushion Air 8lb PE
Tail - Clipped Crescent
Additional Features - CNC Shaped, XFL Armour and Nose Bulbs.
Manufacturing Country - Indonesia
Understanding this bodyboard's technology
 |
1.9lb Kinetic PP (Indonesia)
Lightweight fusion foam compressed at 1.9lb offering instant recoil, enhanced stiffness and compression strength. This foam is 100% waterproof and ideal in mild to warm temperatures.
|
 |
Carbon Fibre/ CFT Stringer
Lightweight filament wound carbon composite rod offering rigidity and durability.
|
 |
55/45 Rails
This rail setup leaves less of your rail in the water and offers the rider less contact with the water and therefore better drive and speed throughout all conditions.
|
 |
Graduated
Graduated channels are a slow rise channel which redirect waterflow to create lift and allow the rider a better grip on the wave.
|
 |
DuPont Surlyn Slick
Surlyn plastic is thin and durable making it the most popular top end slick. Surlyn plastic will bend and stretch before it creases or snaps. This is a must have for intermediate through to advanced riders.
|
 |
Wavecushion 8lb NXLPE (Indo) Decking
Wavecushion decking is a 8lb decking foam. Much like the PE core, the PE decking is soft and flexible. Unlike the PE core, PE decking is used on all top end boards as for the flex and softness which allows riders to create a foam memory. Despite being soft and flexible PE is still extraordinarily durable.
|
 |
Clipped Crescent Tail
The clipped crescent tail is the most popular crescent tail option. This tail will perform when driving, turning, carving and releasing. Clipping the tail allows the rider to maximise their drive and maintain control through the outer concaves and clipped areas.
|
 |
Nose Bulbs
Nose bulbs are a slightly raised area of foam on the nose of the board which create a comfortable spot to grip the nose.
|
 |
CNC Shaping
Short for “computer numerical control”, CNC machines allow shapers to cut boards perfectly to the mm. CNC machines offer the sharpest possible finish to bodyboard manufacturing.
|
 |
Manufacturing Country: Indonesia/ Broady
Bodyboards that come from Indonesia come out of Nick Mesritz’s factory. Nick Mesritz is the owner and shaper of both NMD and VS bodyboards and has more than 20 years experience in shaping, testing and creating wavecraft.
|
|
Bodyboard Size
|
Nose
|
Wide Point
|
NTWP
|
Tail
|
Finished Thickness
|
| 44" |
12 3/8" |
22" |
19" |
18 3/4" |
58mm |
|
45"
|
12 5/8" |
22 1/2" |
19 1/2" |
19 1/8" |
59mm |
